Ruland: CL-12-FZ, 3/4" One-Piece Shaft Collar, Zinc Plated Steel, Clamp Style, 1 1/2" OD, 0.500" Width
| Dimension | |||
| Bore (B) | 0.7500 in | Bore Tolerance | +0.002 in / +0.0005 in |
| Outer Diameter (OD) | 1 1/2 in | Clearance Diameter (C) MAX | 1.808 in |
| Width (W) | 0.500 in | Width Tolerance | +0.003 in / -0.010 in |
| Fastening Hardware | |||
| Forged Clamp Screw | 1/4/2028 | Screw Material | Alloy Steel |
| Hex Wrench Size | 3/16 in | Screw Finish | Zinc Plated |
| Seating Torque | 170 lb-in | Screw Location (R) | 0.545 in |
| Number of Screws | 1 ea | ||
| Additional Information | |||
| Material Specification | 1215 Carbon Steel Bar | Finish Specification | Type II, SC2 Zinc Plating with a Yellow "Trivalent" Chromate Conversion Coating, Meets or Exceeds ASTM B633-98 |
| Manufacturer | Ruland Manufacturing | Country of Origin | USA |
| Temperature | -40°F to 350°F (-40°C to 176°C) | Weight (lbs.) | 0.176 |
| Recommended Shaft Tolerance | +0.0000 in / -0.0005 in | UPC | 63452907276 |
| CERTIFICATIONS/STANDARDS | |||
| ISO 9001:2015 | Certified | Conflict Minerals | Compliant |
| RoHS3 | Compliant | REACH | Compliant |
CL-Inch: CL-12-FZ
- รหัส/รุ่น: CL-12-FZ
- สถานะสินค้า: มีสินค้า
-
1,073.52 บาท
- ราคาไม่รวมภาษี: 1,073.52 บาท
