| Default Battery System Voltage (DC) | 12V | 24V | 12V | 24V | 12V | 24V | 12V | 24V | 48V | 24/48V | 24/48V | 24/48V |
| INVERTER OUTPUT |
| Rated Power | 1KW | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW |
| Surge Rating (20ms) | 3KW | 4.5KW | 6KW | 9KW | 12KW | 15KW | 18KW |
| Capable Of Starting Electric Motor | 1HP | 1HP | 1HP | 2HP | 2HP | 3HP | 3HP |
| Waveform | Pure sine wave/ same as input (bypass mode) |
| Nominal Output Voltage RMS | 100V/110V/120VAC 220V/230V/240VAC(+/-10% RMS) | 220V/230V/240VAC(+/-10% RMS) |
| Output Frequency | 50Hz/60Hz +/-0.3 Hz |
| Inverter Efficiency(Peak) | >88% |
| Line Mode Efficiency | >95% |
| Power Factor | 0.8 |
| Typical Transfer Time | 10ms(max) |
| AC INPUT |
| Voltage | 120VAC/230VAC | 230VAC |
| Selectable Voltage Range | 96~132VAC 155~280VAC(For Personal Computers) |
| Frequency Range | 50Hz/60Hz (Auto sensing) 40-80Hz |
| BATTERY |
| Minimum Start Voltage | 10.0VDC /10.5VDC for12VDC mode (*2 for 24VDC, *4 for 48VDC ) |
| Low Battery Alarm | 10.5VDC +/-0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC ) |
| Low Battery Cutoff | 10.0VDC +/-0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC ) |
| High Voltage Alarm | 16.0VDC +/-0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC ) |
| High Battery Voltage Recover | 15.5VDC +/-0.3V for12VDC mode (*2 for 24VDC, *4 for 48VDC ) |
| Idle Consumption-Search Mode | <25W when power saver on |
| AC CHARGER |
| Output Voltage | Depends on battery type |
| Charger AC Input Breaker Rating | 10A | 30A | 30A | 30A | 40A |
| Overcharge Protection S.D. | 15.7VDC for 12VDC mode (*2 for 24VDC, *4 for 48VDC ) |
| Maximum Charge Current | 35A | 20A | 45A | 25A | 65A | 35A | 75A | 45A | 30A | 65A | 35A | 70A | 40A | 75A | 50A |
| BYPASS & PROTECTION |
| Input Voltage Waveform | Sine wave (grid or generator) |
| Nominal Input Frequency | 50Hz or 60Hz |
| Overload Protection (SMPS Load) | Circuit breaker |
| Output Short Circuit Protection | Circuit breaker |
| Bypass Breaker Rating | 10A | 30A | 30A | 30A | 40A |
| Max Bypass Current | 30Amp |
| SOLAR CHARGER |
| Maximum PV Charge Current | 50A |
| DC Voltage | 12V/24V/48V |
| MPPT Range @ Operating Voltage | 15~80VDC |
| Maximum PV Array Open Circuit Voltage | 90VDC |
| Maximum Efficiency | >97% |
| Standby Power Consumption | <2W |
| MECHANICAL SPECIFICATIONS |
| Mounting | Wall mount |
| Dimensions (W*H*D) | 426*206*178 mm | 601*206*178mm |
| Net Weight (Solar CHG) kg | 16.5 | 17 | 21.1 | 20 | 26 | 24.5 | 24.8 | 38.2 | 35.8 | 45.2 | 45 | 45.2 | 45 |
| Shipping Dimensions(W*H*D) | 570*335*300mm | 750*335*300mm |
| Shipping Weight (Solar CHG) kg | 19.3 | 20 | 24.1 | 22.8 | 29.1 | 27.5 | 27.5 | 42.3 | 40 | 49.5 | 49.3 | 49.5 | 49.3 |
| OTHER |
| Operation Temperature Range | 0°C to 40°C |
| Storage Temperature | -15°C to 60°C |
| Audible Noise | 60dB MAX |
| Display | LED+LCD |
