| Default Battery System Voltage | 12V/24V/36V/48VDC (Auto detection) |
| CONTROLLER INPUT |
| PV Open Circuit Voltage | 100VDC@12V/ 145VDC @24V/ 145VDC @36V/ 145VDC @48V |
| PV Array MPPT Voltage Range | 16VDC~100VDC / 32VDC~130VDC / 48VDC~130VDC / 64VDC~130VDC |
| Max PV Input Power(12V) | 600W | 800W | 1050W |
| Max PV Input Power(24V) | 1200W | 1600W | 2100W |
| Max PV Input Power(36V) | 1800W | 2400W | 3150W |
| Max PV Input Power(48V) | 2400W | 3200W | 4200W |
| BATTERY |
| Absorption Voltage | 12.5VDC/25.0VDC/37.5VDC/50.0VDC |
| Refloat Voltage | 13.7VDC/27.4VDC/41.1VDC/54.8VDC |
| Float Voltage | 14.3VDC/28.6VDC/42.9VDC/57.2VDC |
| Low Voltage Protection Point | 10VDC/20VDC/30VDC/40VDC |
| Temperature Compensation coefficient | -3mv/°C /cell (25°C vef) |
| BATTERY |
| Peak Conversion efficiency | 98% (MPPT Efficiency 99%) |
| Max Charging Current | 45 amps continuous @ 40°C ambient | 60 amps continuous @ 40°C ambient | 80 amps continuous @ 40°C ambient |
| GENERAL SPECIFICATION |
| Radiating mode | Fan cooling |
| DISPLAY & PROTECTION |
| LED indication | Systematic operation, LV indication, LV protection, over charge protection, short circuit protection |
| LCD display | Charge voltage, charge current, voltage of storage battery, capacity of storage battery, output current |
| Alarm Protections | PV array short circuit, PV reverse polarity;Battery reverse polarity, Over charging protection;Output short circuit protection;Low voltage protection for storage battery. |
| MECHANICAL SPECIFICATIONS |
| Mounting | Wall mount |
| W*H* D(mm)/Net Weight(kg) | 167.6*257.1*82.9mm/3kg |
| OTHER |
| Environmental Rating | Indoor |
| Operation Temperature Range | -25~55°C |
| Ambient humidity | 0~90% relative humidity(non-condensing) |
| Altitude | ≤3000m |
| Loading(20GP/40GP/40HQ) | 3000pcs / 6000pcs / 7200pcs |
